Energy storage system
High Voltage Lithium Battery (HV-100K)
●Small size,saving chassis space
●Easy to install in any angles
●Good compatibility and adaptability
●Long cycle life with multiple application modes
●Using automotive-grade battery cells
●Multiple cabinets are connected in parallel
●Support MW-level power
| Model Product | ODM/HV-61K 614.4V100AH | ODM/HV-100K 358.4V280AH | ODM/HV-129K 460.8V280AH |
| Nominal Voltage | 614.4V | 358.4V | 460.8V |
| Nominal Capacity | 100AH | 280 | 280 |
| Dimension Moudle(mm) | 440*442*133*2 | 483*245*792*7 | 483*245*792*9 |
| Dimension RACK(mm) | 600*550*1004*2 | 1080*800*1250 | 1080*800*1530 |
| Weight(kg) | 620KG | 930KG | 1195KG |
| Specifications | |||
| Nominal Capacity(KWH) | 61.44 | 100.3 | 129 |
| Discharge Cut-Off Voltage(V) | 528 | 308 | 396 |
| Charge Cut-Off Voltage (V) | 681.6 | 397.6 | 511.2 |
| Recommend Charge/Discharge Current(A) | 60 | 100 | 100 |
| Max.Charge/Discharge working Current(A) | 100 | 200 | 200 |
| Counication | RS485/RS232/CAN | ||
| Working Temperature | 0'C-50'℃ Charge -10'℃ ~50'℃ Disharge | ||
| Transport or Storage Temperature Range | -20°C-60°C | ||
| Certification | CE/IEC/ULUN38.3/MSDS | ||
| Design Life | 15years+ | ||
| Cycle Life | (0.5C10.5C-80%DOD)>6000 times | ||
| Series Function | Support 16 units in Series | ||
| Certification | UN38.3/MSDSIROHS | ||
