Solar lighting system (ODM SLK-T001)

Product Introduction:

Solar lighting kit is from solar panel, solar controller, battery, through the professional assembling to be an easy using product; after some times of product upgrading, stands on the head of solar product peer. The product has many highlights, easy installation, maintenance free, safety and easy to solve the basic use of electricity......

Application Scenario:

Connection Diagram:

Specification:

Model	SLK-T001
	Option 1		Option 2
Solar Panel
Solar panel with cable wire	15W/18V		25W/18V
Main Power Box
Built in controller	6A/12V PWM
Built in battery	12.8V/6AH(76.8WH)		11.1V /11AH(122.1WH)
Radio/MP3/Bluetooth	Yes
Torch light	3W/12V
Learning lamp	3W/12V
DC output	DC12V * 4pcs  USB5V * 2pcs
Accessories
LED bulb with cable wire	2pcs*3W LED bulb with 5m cable wires
1 to 4 USB charger cable	1 piece
* Optional accessories	AC wall charger, fan, TV, tube
Features
System protection	Low voltage, overload ,load short circuit protection
Charging mode	Solar panel charging/AC charging(optional)
Charging time	Around 5-6 hours by solar panel
Package
Solar panel size/weight	360*460*17mm / 1.9kg	340*560*17mm/2.4kg
Main power box size/weight	280*160*100mm/1.8kg
Energy Supply Reference Sheet
Appliance	Working time/hrs
LED bulbs(3W)*2pcs	12-13	20-21
DC fan(10W)*1pcs	7-8	12-13
DC TV(20W)*1pcs	3-4	6
Mobile phone charging	3-4pcs phone charging full	6pcs phone charging full

Picture:
